Aluminum Awning Windows

Top-hinged windows that open outward at the bottom, letting the frame itself act as an awning — ventilation stays on even in light rain. Engineered for monsoon seasons and coastal exposure, standard or stacked in bands.

Get a Project Quote
See Window Projects

6063-T6

Aluminum Grade

1.8mm

Min. Wall Thickness

45d

Avg. Delivery

0%

Defect Rate

Awning Window

01 / OVERVIEW

Tilt and turn window handle hardware detail

What is a Awning Window?

An awning window is hinged along the top edge and opens outward at the bottom, pushed out by friction stay arms. Because the open sash tilts outward like a small awning, it keeps ventilation going even during light-to-moderate rain — water runs off the glass instead of into the room.

BOYCE’s awning systems use adjustable friction stays rated to hold the sash open at any angle, paired with EPDM sealing and hidden drainage so the frame stays weathertight when closed.

Get a Project Quote

More Configurations

02 /  SERIES

Awning window series.

From a single ventilation band to a full stacked wall, we configure awning systems around your ventilation and privacy needs.

Get a Project Quote

Awning Window Specification

03 / SPECIFICATION

Profile Thickness
1.6mm — 1.8mm
Opening Type
Top-hinged, outward-opening at the base
Handle Finish
Black and silver crank/push-bar options
Stay Arms
Adjustable friction stay, holds any open angle
Locking Points
Black multi-point lock, upgradeable
Frame Grade
6063-T6 aluminum
Thermal Break
PA66 nylon strip, multi-cavity structure
Sealing
EPDM insulation strip, tested drainage design
Glass Options
Single / double glazing, Low-E available
Finish Type
Powder coating / fluorocarbon (PVDF)
Standard Colors
Black, dark grey, bronze, custom RAL matching
Coastal Option
PVDF fluorocarbon for high-UV, high-salinity sites
Standard Sash Width
500mm — 1200mm
Standard Sash Height
400mm — 900mm
Custom Sizing
Confirmed against site dimensions via shop drawing
Hardware Brand
GU, Roto, or equivalent — brand confirmed in quote
Stay Arm Type
Dual friction arms, rated for repeated cycling
Insect Screen
Optional fixed interior screen

Window systems, by project type.

See how we craft your windows in a whole new way across all our projects.

Awning Window | Friction Stay Mechanism

Dual friction stay arms hold the sash open at any angle you choose, and are rated for years of repeated opening and closing without loosening.

Awning Window | Rain-Resistant Ventilation

The outward-tilting sash acts as its own small awning, so you can keep ventilation running during light rain without water getting inside.

Awning Window | Secure Locking

A multi-point locking handle keeps the sash secure when closed, with a restrictor option to limit the open gap for ground-floor installations.

about Aluminum Awning Windows- FAQ

What are the advantages of aluminum awning windows?
+
Ventilation continues even in light rain, the narrow opening angle makes forced entry harder, and the closed sash has no visible hardware breaking up the view — all in a frame resistant to coastal and high-heat corrosion.
What are the drawbacks compared to casement windows?
+
An awning window opens less fully than a casement, so total airflow is somewhat lower, and it isn't practical as an emergency exit. It's usually paired with fixed or casement windows rather than used alone for a whole room.
Can an awning window be used as an emergency exit?
+
Generally no — the opening is limited by the stay arm length and hinge position. For bedrooms requiring an egress opening, we'd recommend a casement or larger opening window alongside any awning units.
How much do aluminum awning windows cost?
+
Pricing depends on size, glass makeup, hardware brand and coating type. Send your window schedule and we'll return an itemized quote — not a lump-sum estimate — within 24 hours.
Are awning windows weatherproof in heavy monsoon rain?
+
In light-to-moderate rain, yes — the tilted sash sheds water effectively. In driving, wind-blown rain, we recommend closing the sash, same as any operable window.
